IXIA by Keysight

IxVM

IxVM - семейство продуктов компании Ixia специально разработанных для тестирования виртуализированных активов и сред, используя при этом надежные инструменты Ixia, которые применяются для тестирования аппаратного сетевого оборудования уже более десяти лет.

Ключевые особенности

  • IxVM;

Читать полное описание
Number of IxVM ports per load module Depends on IxVM module type and host system
Number of IxVM load modules per vChassis 32
Number of IxVM ports per vChassis 128
Line speed Up to 10Gbps per VM (IxNetwork and IxLoad)
Interface protocols MAC, VLAN, IPv4 (ARP, PING), IPv6 (NDP, SLAAC, PING)
Host protocol emulation support DHCPv4/v6 (Client, Relay Agent and Server), PPPoE/L2TP (Client and Server), IGMP/MLD (Host and Querier)
Data center bridging protocol emulation support DCBX, FIP/FCoE, FCF, VXLAN, TRILL, SPBM, FabricPath, OpenFlow
Routing/bridging protocol emulation support BFD, BGP4/4+, EIGRPv4/6, ISISv4/6, LDP, OSPF/OSPFv3, PIMv4/v6, RIP/RIPng, RSVP-TE, xSTP
Carrier Ethernet protocol emulation support CFM, Y.1731, PBB-TE, Link OAM, TWAMP
Application traffic protocols HTTP, SSL, FTP, TFTP, DNS, DHCP, LDAP, RADIUS, SMTP, POP3, IMAP, SMB, NFS, iSCSI, Storage I/O
Stream definitions per port 256
Number of transmit flows per port (sequential) Billions
Number of transmit flows per port (non-sequential values) 4,096
User defined fields (UDF) Counter, Nested Counter, Value List, Range List, Random
Transmit engine Packet generation with timestamps, sequence numbers, and packet group signatures
Data pattern per stream Increment Byte, Increment Word, Decrement Byte, Decrement Word, Repeat, Random, Custom
Frame length controls Fixed, Increment, Decrement, Random (Uniform Distribution, Weight Paris, IMIX), Auto
Error generation Invalid IP checksum
Receive engine Packet filtering, capturing, real-time latency, latency bin and sequence checking for each packet group
Trackable receive flows 4,096
UDS filters Destination MAC, Source MAC, Frame Size, Pattern
Flow control N/A
Latency measurements Based on NTP
IxVM Controller OS support (IxVM vChassis) Windows 7 Professional 32-bit
Host OS support / hypervisor support
IxNetwork Ixia-enhanced kernel (based on RHEL/CentOS 6.3)
RPM
IxLoad Ixia-enhanced kernel (based on RHEL/CentOS 6.3)
Guest OS support / IxVM load modules
Distribution formats
VMware: OVA
KVM IxVM self-extracting installer
Bare-metal: RPM
