IXIA by Keysight
IxNetwork
Решение IxNetwork тестирует устройства IP маршрутизации и коммутации и оборудование широкополосного доступа. Обеспечивает генерацию трафика и эмуляцию полного диапазона протоколов: routing, MPLS, Layer 2/3 VPN, Carrier Ethernet, broadband access и data center bridging.
Ключевые особенности
- IxNetwork;
Технические характеристики
| Routing | |
| RIP, RIPng | RFC 1058, RFC 2453 |
| OSPFv2/v3 | RFC 2328, RFC 2740 |
| ISISv4/v6 | ISO/IEC 10589 |
| EIGRP, EIGRPv6 | Cisco proprietary |
| BGP-4,BGP+ | RFC 1771, RFC 2545 |
| MPLS | |
| MPLS-TP | FC 5654 / RFC 5860 / RFC 5921 / RFC 5586 / RFC 6371 / RFC 6378 / RFC 6426 / RFC 6428 / RFC 6478 / draft-ietf-mpls-tp-loss-delay-00 / draft-bhh-mpls-tp-oam-y1731-06 |
| MPLS OAM | RFC 4379: detecting MPLS data plane failures / RFC 5884: bidirectional forwarding detection (BFD) for MPLS label switched paths (LSPs) / RFC 5085: pseudowire virtual circuit connectivity verification (VCCV), a control channel for pseudowires / RFC 5885: B |
| Multicast VPN: GRE, mLDP, RSVP-TE P2MP | Draft-Rosen/RFC 6037 RFC 6514 |
| EVPN, PBB-EVPN | draft-ietf-l2vpn-evpn-04 / draft-ietf-l2vpn-pbb-evpn-06 |
| VPLS | |
| 6PE | RFC 4798 |
| BGP auto-discovery with LDP FEC 129 support | draft-ietf-l2vpn-signaling-08 RFC 4447 |
| VPLS-LDP | RFC 4762 draft-ietf-l2vpn-signaling-08 |
| VPLS-BGP | RFC 4761 |
| High-Availability | |
| BFD | draft-ietf-bfd-base |
| IP Multicast | |
| IGMPv1/v2/v3 | RFC 1112, RFC 2236, RFC 3376 |
| MLDv1/v2 | RFC 2710, RFC 3810 |
| PIM-SM/SSM, PIM-BSR | RFC 2362, RFC 4601 |
| Multicast VPN, VPNv6 | IETF draft-rosen-l3vpn-mvpn / draft-ietf-l3vpn-2547bis-mcast-07.txt (RSVP-TE P2MP Support) / draft-ietf-l3vpn-2547bis-mcast-bgp-05.txt (A-D route 1,3,4,5,7) |
| Switching | |
| STP/RSTP | IEEE 802.1D/802.1W |
| MSTP | IEEE 802.1s |
| PVST+/RPVST+ | Cisco proprietary |
| Link Aggregation (LACP) | IEEE 802.3ad |
| LLDP | IEEE 802.1AB |
| Carrier Ethernet | |
| Link OAM | IEEE 802.3ah-2004 Clause 57 |
| CFM | IEEE 802.1ag-2007 |
| Service OAM | ITU-T Y.1731-2006 |
| PBT/PBB-TE | Nortel Standard/IEEE 802.1Qay |
| ESMC | ITU-T G.8264/Y.1364 SyncE |
| PTP | IEEE 1588-2008 (version 2) / G.8265.1 Telecom Profile |
| E-LMI | MEF 16 |
| Broadband | |
| ANCP | draft-ietf-ancp-protocol-02 / draft-ietf-ancp-framework-05 |
| PPPoX | RFC 1331, RFC 2516, RFC 4241 |
| DHCPv4 Client/Server / DHCPv6 Client/Server | RFC 2131 / RFC 3315, RFC 3363 |
| L2TPv2 | RFC 3817 |
| L2TPv2 RFC 3817 | RFC 2865 |
| IPv6 Autoconfiguration (SLAAC) | RFC 4862 |
| IPTV | IGMP - RFC 1112, RFC 2236, RFC 3376 / MLD - RFC 2710, RFC 3810 |
| AMT | IETF draft-ietf-mboned-auto-multicast-12 |
| Authentication | |
| 802.1x | IEEE 802.1x |
| WebAuth | Cisco and HP implementations |
| Cisco NAC | Cisco proprietary |
| Data Center | |
| Priority flow control | IEEE 802.1Qbb |
| FCoE/FIP | T11 FC-BB-5 |
| LLDP/DCBX | CIN 1.0/Pre-CEE, IEEE Baseline 1.01/ CEE, IEEE 802.1Qaz |
| VNTAG/VIC | Cisco proprietary |
| TRILL | RFC6325 / RFC6326 / RFC6327 |
| SPBM | IEEE 802.1aq |
| VEPA | 802.1Qbg draft 2.1 |
| OpenFlow | ONF v1.0/v1.3.1 |
| VXLAN | draft-mahalingam-dutt-dcops-vxlan-04 |
Файлы для скачивания
- Описание решения IxNetwork - Network Topology Testing and Traffic Analysis (EN)
- Описание решения IxNetwork AppLibrary: Application Intelligence for Realistic L2-7 Traffic (EN)
Внешний вид
